HSB-006
Share This Product:
  • HSB-006

HSB series 6 Poles of connector

35Amp 6 pin Heavy Duty Wire Connector



In terms of operational safety, its patented independent grounding point is arranged in the shell, and it is directly connected to the metal shell to protect the electrical safety of the person. In addition, the number of fixing screws has been reduced by half, which greatly reduces the time cost of installation.

Rated current

35A

Rated voltage

400/690V

Flammability acc.to UL94

V0

Degree of protection acc.to DIN40 050

IP65

Terminal

Screw terminal / Spring terminal/Crimp terminal

Thread

M25/M32/PG21/PG29
